产品名称：	10%聚己二酸乙二醇酯/401 色谱纯乙酸乙酯的测定填充柱
产品型号：	10%聚己二酸乙二醇酯/401
品牌：	1356
产品数量：
产品单价：	面议
日期:	2021-03-03

10%聚己二酸乙二醇酯/401 色谱纯乙酸乙酯的测定填充柱的详细资料

色谱纯乙酸乙酯的测定填充柱
色谱纯乙酸乙酯的测定填充柱 详细信息：

名称：填充柱

固定相：10%聚己二酸乙二醇酯

担体：401有机担体

粒度：0.18-0.28mm（60-80目）

规格：2m*3mm

型号：10%EGA/401

应用：GB 12589-90 化学试剂 乙酸乙酯，GB/T 12589-2007 化学试剂 乙酸乙酯

乙酸乙酯纯化系统以及色谱纯乙酸乙酯生产系统，涉及化工产品纯化技术领域，该乙酸乙酯纯化系统通过第二温度传感器可以精确测定回流罐内冷凝液的温度，通过温度传感器可以精确测定精馏塔顶部的温度，综合冷凝液的温度情况和精馏塔塔顶的温度情况，来确定回流塔顶的冷凝液的量，从而使塔顶的温度维持在一个相对恒定的范围内，以精馏的效果。同时，在精馏之前对工业级乙酸乙酯先进行一次蒸馏提纯，进一步提高了精馏过程的纯化效果。该色谱纯乙酸乙酯生产系统包括上述乙酸乙酯纯化系统和乙酸乙酯制备系统，其设备简单、操作方便、纯化效果好，可用于大规模的工业生产。

浩瀚色谱（山东）应用技术开发有限公司，，研发10%聚己二酸乙二醇酯/401有机担体填充柱，热导检测器，面积归一法测定色谱纯乙酸乙酯的纯度及杂质，柱效高，分离好，面积归一法定量。

色谱纯乙酸乙酯的测定填充柱  测试谱图：


Determination of Chromatographic Pure Ethyl Acetate Packed Column
Packed column for the determination of chromatographic pure ethyl acetate Details:

Name: Packed column

Stationary phase: 10% polyethylene adipate

Carrier: 401 organic carrier

Particle size: 0.18-0.28mm (60-80 mesh)

Specification: 2m*3mm

Model: 10%EGA/401

Application: GB 12589-90 chemical reagent ethyl acetate, GB/T 12589-2007 chemical reagent ethyl acetate

The ethyl acetate purification system and the chromatographic pure ethyl acetate production system relate to the technical field of chemical product purification. The ethyl acetate purification system can accurately measure the temperature of the condensate in the reflux tank through the second temperature sensor, and the first temperature sensor can accurately measure the temperature of the condensate in the reflux tank. Measure the temperature of the top of the rectification tower, combine the temperature of the condensate and the temperature of the top of the rectification tower, to determine the amount of condensate that is refluxed to the top of the tower, so that the temperature at the top of the tower is maintained in a relatively constant range , In order to ensure the effect of rectification. At the same time, the industrial-grade ethyl acetate is distilled and purified once before the rectification, which further improves the purification effect of the rectification process. The chromatographic pure ethyl acetate production system includes the above-mentioned ethyl acetate purification system and ethyl acetate preparation system, and has simple equipment, convenient operation and good purification effect, and can be used for large-scale industrial production.

Haohan Chromatography (Shandong) Applied Technology Development Co., Ltd. keeps pace with the times and develops 10% polyethylene adipate/401 organic carrier packed column, thermal conductivity detector, and area normalization method for the determination of chromatographic pure ethyl acetate Purity and impurities, high column efficiency, good separation, and area normalization method for quantification.

Packed column for the determination of chromatographic pure ethyl acetate Test spectrum:
